Description
41% Ultimate 10-300 – Short Kit
New for 2022 the 41% Ultimate, Based on the phenomenal flying 52% Brother, The 41% Model employs the latest in design Elements and innovative construction, To Bring a model of high strength, Rigidity and Low weight.
Due to the Ultimate’s Design of a Long tail Moment, Super light weight construction & correct airfoil, The ultimate is the choice for Precision (Imac) flying but also extremely capable at low and slow 3D flying.
The Ultimate from SMD is the pinnacle of the biplane platform and is an amazing all round model that will not disappoint!
Features:
- High level of interlocking construction, For quick, accurate building & Strength
- Removable horizontal stabilizers (With servos installed into each Stab)
- Precut slots in Tail plane to suit Robart hinges
- Cable path in aft of Fuselage for servo wires
- Fuel tank, ignition & Battery tiedown points
- Built in Canister Muffler Mounting
- 6mm CFK tube wing spars – High strength and low weight.
Specifications:
- Weight: 30lb (14kg)
- Wingspan 95.4″ (2396mm)
- Length 101″ (2574mm) – With Spinner
- Engine 100-120cc 2 Stroke or 120-140cc 4 Stroke
- Servos: 7x (25kg+) + 1x Throttle
- Spinner size: 5″
- Wheel size: 4″
- Wing tube Socket size: 29mm OD (Maximum OD)
- (Recommend 28mm OD Aluminum or Carbon wing Tube)
- Tail tube socket size: 8mm OD
- (Recommend 7mm OD Carbon rod or Tube)
(Engine fitment Note: Due to the scale cowl shape and Depending on engine choice it may be required to run a small propeller hub Extension (10-15mm) to allow the carburetor on most updraft style carburetors engines to clear the cowling and not rub/interfere)
The Short kit includes:
- Precision Laser cut wooden parts from premium European woods
- CNC Laser cut Stainless steel Top wing mount and Flying wire mounting set
- CNC milled TUFNOL Control Horns
- 1:1 Scale detailed Printed wing plans + Digital Instructions.
- A comprehensive list of all the Components & Materials required to complete the model.
- Premium GFK Cowling (Produced from CNC created mold for digital precision, Shape & Symmetry)
- Premium CFK and GFK Main Under carriage
- Lexan Vacuum formed Canopy
- Premium Light weight GFK Wheel Pants
Please note: As each kit is normally manufactured to order, please allow 2-6 weeks for Manufacture and shipping dispatch, With the wood kit being manufactured and shipped first and then Composite parts to follow shortly after
However we will keep you updated at each stage of your kits Production.
Additional Materials & Items List
Please see our Build Thread in progress on Flying Giants, Please click the link
https://www.flyinggiants.com/forums/showthread.php?t=333147
John –
I Was waiting for an Ultimate in this size and Skip Models deliver an awesome model that not only looks scale, But Builds like a Dream, One of the easiest building model kits ive had.!!. Such a great laid out and complete kit. Everything is labeled and bagged easy to id and easy to follow, Just Excellent.
Josh K –
Fantastic looking box of Balsa. All nicely labled and ready to go. Hours saved in sorting balsa. The parts list makes ordering a simple task than searching endlessly on multiple sites.
Contact with Lee was frequent and he kept me up to date. Especially when I received my kit he checked up to ensure everything was in order. Customer service A1.
Darrell Smith (verified owner) –
Hello everyone, I’ve been building model airplane kits for over 20 years and I have to say this has been one of the most enjoyable kits I’ve ever built there’s a lot of work but very easy to build a big thank you to skip model design for a beautiful airplane and kit well worth the time And effort five stars in my humble opinion
